The Ford 4000 is a 2WD utility tractor. The first generation was manufactured from 1962 to 1965, the second from 1965 to 1967. This is the third generation was manufactured by Ford in Highland Park, Michigan, USA from 1968 to 1975. The Ford 4000 is equipped with one of two engines: a 3.3 L three-cylinder diesel or gasoline engine and one of two transmissions: the Dual Range transmission with 8 forward and 2 reverse gears or the Select-O-Speed transmission with 10 forward and 2 reverse gears.
The Ford 4000 utility tractor used the Ford gasoline or diesel engine. It is a 3.3 L, 3,294 cm2, (201.0 cu·in) three-cylinder natural aspirated engine with 112.0 mm (4.41 in) of the cylinder bore and 112.0 mm (4.41 in) of the piston stroke. The compression ratio rating is 16.8:1 for the diesel version.
- Unequaled performance from your Ford Tractor. This manual has been prepared to acquaint you With the many features of your new Ford Tractor. Most Of the Information presented here is general and to both Series 2000 and 4000 All purpose Many of the features covered in this manual are optional equipment on some models and standard on others.
- Ford 2000 3000 4000 Series Tractor Service Repair Shop Manual. Ford 2310 2600 2610 3600 3610 4100 4110 4600 4610 4600SU 4610SU Tractor Service Repair Shop Manual. Ford 2810 2910 3910 Tractor Service Repair Shop Manual. Ford 3230 3430 3930 4630 4830 Tractor Service Repair Shop Manual. Ford 5000 5600 5610 6600 6610 6700 6710 7000 7600 7610 7700.
- Ford Tractor Service Manuals. 1000 Series 2000 Series 3000 Series 3400 Series 3500 Series 3550 Series 4000 Series 4400 Series 4500 Series.
The Ford 4000 is equipped with manual or hydraulic power steering, mechanical wet disc brakes, open operator station and 60.5 liters (16 US gal.; 13.3 Imp. gal) fuel tank.
Following attachments are available for the Ford 4000 utility tractor:
- Ford 771 loader
- Ford 772 loader
Ford 4000 Specifications
| General Specifications | |
| Model | Ford 4000 |
| Length | 3,470 mm (136.6 in) |
| Width | 1,710 mm (67.3 in) |
| Height | 2,150 mm (84.6 in) |
| Wheel base | 2,140 mm (84.3 in) |
| Weight | 2,215 kg (4,885 lbs) |
| Fuel tank capacity | 60.5 liters (16 US gal.; 13.3 Imp. gal) |
| Battery | 12V, 80Ah (gasoline), 128Ah (diesel) |
| Cabin type | Open operator station |
| Engine | |
| Engine model | Ford |
| Engine type | Four-stroke, liquid-cooled, inline |
| Cylinders | 3 |
| Fuel type | Diesel |
| Displacement | 3.3 L, 3294 cm2, (201 cu·in) |
| Bore and stroke | 112.0 mm X 112.0 mm (4.41 in X 4.41 in) |
| Compression ratio | 16.5:1 |
| Horsepower | – |
| Starter | Electric |
| Oil capacity: | 7.6 L (8 US. qt, 6.7 Imp. qt.) |
| Coolant capacity: | 13.2 L (13.9 US. qt, 11.6 Imp. qt.) |
| Engine | |
| Engine model | Ford |
| Engine type | Four-stroke, liquid-cooled, inline |
| Cylinders | 3 |
| Fuel type | Gasoline |
| Displacement | 3.3 L, 3294 cm2, (201 cu·in) |
| Bore and stroke | 112.0 mm X 112.0 mm (4.41 in X 4.41 in) |
| Horsepower | – |
| Starter | Electric |
| Oil capacity: | 7.6 L (8 US. qt, 6.7 Imp. qt.) |
| Coolant capacity: | 13.2 L (13.9 US. qt, 11.6 Imp. qt.) |
| Transmission and chassis | |
| Chassis | 4×2 2WD |
| Steering type | Manual or hydraulic power |
| Brakes | Mechanical wet disc |
| Final drive | Inboard planetary |
| Transmission model | Dual Range |
| Transmission type | Gear type |
| Gears | 8 forward and 2 reverse |
| Speed | Forward: 27.0 kmh (16.8 mph) Reverse: 13.0 (8.1 mph) |
| Transmission oil capacity | 12.5 L (3.3 US. gal, 2.7 Imp. gal.) With independent PTO: 16.0 L (4.2 US. gal, 3.5 Imp. gal.) |
| Transmission model | Select-O-Speed |
| Transmission type | Gear type |
| Gears | 10 forward and 2 reverse |
| Speed | Forward: 28.3 kmh (17.6 mph) Reverse: 8.2 (5.1 mph) |
| Transmission oil capacity | 11.6 L (3.1 US. gal, 2.6 Imp. gal.) |
| Tires | |
| Front tires | Ag: 6.00-16 |
| Rear tires | Ag: 12.4-38 |
Operators Manual Ford 4000 Tractor
| Three-Point Hitch | |
| Caterogy | II/I |
| Control type | – |
| Lift capacity (at ends) | 1450 kg (3197 lbs) |
| PTO (Power take-off shaft) | |
| Rear PTO type | Transmission or independent |
| Rear PTO speed | 540, 1,000 rpm |
| Hydraulic system | |
| Hydraulic type | Open center |
| Pressure | 2500 psi (172.4 bar) |
| Pump flow | 5.4 gpm (20.4 lpm) |
| Steering flow | 4.5 gpm (17 lpm) |
| Total flow | 9.9 gpm (37.5 lpm) |
